With innovative hot air circulation technology, it achieves 99% carbonization efficiency and cuts processing time drastically—from 24 hours to just 6–8 hours. Suited for industrial and commercial use, the furnace features energy-saving operation (combustible gas recovery), eco-friendly emission controls, and consistent output of uniform charcoal pellets for metallurgical, fuel, and filtration applications.
The biomass carbonization furnace follows an integrated workflow:
1. Raw materials (pellets or logs) are fed into the chamber and ignited under controlled oxygen-limited conditions.
2. High-temperature anoxic pyrolysis generates premium charcoal, combustible gas, and wood tar simultaneously.
3. An intelligent environmental protection system purifies exhaust gas through a three-stage pipeline (roof → water-cooling box → air blower), removing over 95% of particulates.
4. Combustible gas is recycled as auxiliary fuel, and wood tar is refined into chemical raw materials—enabling a zero-waste green production cycle.
Model | J0508 | J0812 | J1015 | J1218 | J1422 |
Feed Capacity | 0.4-0.7m³/h | 2-5m³/h | 7-9m³/h | 10-13m³/h | 13-17m³/h |
Reactor Size | Ø500 | Ø800 | Ø1000 | Ø1200 | Ø1400 |
Total Power | 26kw/h | 40kw/h | 45kw/h | 60kw/h | 72kw/h |
Floor Area | 25×15×6m | 30×15×7m | 35×15×7m | 45×15×10 | 50×15×10m |
Conformation | Double cyiinder, double sealed, single fumace | ||||
Heat Source | Diesel, Natural Gas, LPG, Biomass, etc. | ||||
Cooling Method | Recycling Water Cooling | ||||
Raw material | Biomass waste: sawdust, coconut shells, olive shells, palm shells,bamboo, etc. Sludge: civil, municipal, industrial, etc. | ||||
